UBE Aquafarmig ABS Float

UBE Aquafarmig ABS Float

Material : ABS resin
Configuration: Round float with one ear each aligned on the both spheres

Item No. Diameter Depth Weight Bouyancy Bouyancy Dia.of Hole Packing Color
(mm) (m) (g) (N) (kgf) (mm)
CHN-300 297 100 1,560 123.82 12.63 27 4 Black, Yellow, Red
CHN-360 360 100 2,630 216.72 22.11 40.5 4
CHN-400 400 100 3,490 297.03 30.31 40 4
CHN-420 420 100 4,150 345.12 35.22 40 4
CHN-450 455 100 5,950 427.20 43.59 47 4

(Tolerance±3%)

Material : ABS resin
Configuration: Oval float with one ear each aligned on the both spheres
Feature: Its oval shape works to mitigate the wave resistance and reduce vertical vibrations of the float.

Item No. Diameter Depth Weight Bouyancy Bouyancy Dia.of Hole Packing Color
(mm) (m) (g) (N) (kgf) (mm)
FU-10 260 x 491 100 1,665 117.76 12.02 28 4 Yellow, Red
FU-12 310 x 615 100 2,600 198.46 20.25 39 4
FU-13 353 x 676 100 3,400 297.93 30.40 39 4
FU-15 420 x 800 100 6,600 503.00 51.33 45 3

(Tolerance±3%)

Material : ABS resin
Configuration: Round float with two ears aligned on the half sphere

Item No. Diameter Depth Weight Bouyancy Bouyancy Dia.of Hole Packing Color
(mm) (m) (g) (N) (kgf) (mm)
A-300 300 100 1,620 124.35 12.69 28 4 Red
A-360 360 100 2,500 217.30 22.20 33 4

(Tolerance±3%)

Material : ABS resin
Configuration: Round float with two ears each aligned on the both spheres

Item No. Diameter Depth Weight Bouyancy Bouyancy Dia.of Hole Packing Color
(mm) (m) (g) (N) (kgf) (mm)
A-300F 300 100 1,770 124.28 12.68 28 4 Red
A-360F 360 100 2,690 218.30 22.28 33 4
A-400F 399 100 3,800 295.65 30.17 37.5 4

(Tolerance±3%)
